China Fully Automatic Professional Square Automated Donut Machinery Production Line
Features of donut fryer equipment: 1. The mesh belt is made of stainless steel, adopts frequency conversion step less speed regulation, and the frying time can be adjusted according to the product process. 2. The upper and lower double-layer mesh b
Features of donut fryer equipment:
1. The mesh belt is made of stainless steel, adopts frequency conversion step less speed regulation,
and the frying time can be adjusted according to the product process.
2. The upper and lower double-layer mesh belts are used for transmission, and the product is
sandwiched between the double-layer mesh belts to prevent the product from floating.
3. Equipped with an automatic lifting system, the upper cover and the mesh belt can be raised and
lowered, which is convenient for manual cleaning.
4. Equipped with a dynamic circulation system to filter out the oil residue during the production process.
5. It has the functions of automatic slag discharge and automatic scraping, which can discharge the
generated residues from the body at any time, prolonging the service life of edible oil.
6. There is a high-efficiency thermal conductivity device inside the equipment, and the energy utilization
efficiency is high.The whole machine is made of food grade 304 stainless steel, which is hygienic and
easy to clean.
|
MODEL |
Mesh belt width(mm) |
Power（KW) |
voltage（V) |
temperature range（℃） |
Oil capacity(l) |
size(mm) |
capacity（kg/h） |
|
AWTQ-300 |
600 |
48-60 |
380 |
0-300 |
600 |
3000*900*2500 |
100-300 |
|
AWTQ-400 |
600 |
80-98 |
380 |
0-300 |
1000 |
4000*900*2500 |
200-400 |
|
AWTQ-500 |
600 |
98-120 |
380 |
0-300 |
1200 |
5000*900*2500 |
300-500 |
|
AWTQ-600 |
1000 |
120-180 |
380 |
0-300 |
1800 |
6000*1500*2500 |
400-600 |
|
AWTQ-800 |
1000 |
180-200 |
380 |
0-300 |
2200 |
8000*1500*2500 |
1000-1200 |
